Powering Your Adventure with Clayton Power

At Vanz Adventures, we understand the importance of reliable power supply for your campervan adventures. That's why we offer the high-quality Clayton Power Supply to keep you connected, no matter where your journey takes you.

Its easy just plug in and go!

LPS II 2500 - 1 kWh

230 V/50 Hz output

Peak: 4000 W

Power: 2500 W

12 V output

60 Seconds: 270 A

Continously: 180 A

Built-in Li-Ion Battery

Efficient energy: 1 kWh

Capacity: 1320 Wh (100 Ah)

Charging

Alternator: 500 W / SC: 1000 W

Solar panels: 400 W

Mains: 750 W



All in One built in 1 kWh Li-Ion battery, allowing you to charge quickly and efficiently from Alternator, Mains or Solar panels. With a built-in lithium battery the LPS is extremely compact and has a very long lifetime, but it is not possible to change the built-in lithium battery. There are currently more than 35,000 Clayton Power products in use across the UK and Europe.

The meaning of 1 kWh power.

The lithium battery capacity of 1 kWh means that you can run an application with a consumption of 1000 W in one hour, 500 W for two hours and 250 W for four hours.
Example: Power tools 500 W x 1 hour + Light 150 W x 5 hours = 1,25 kWh

The number of cycles.

The battery can handle 2000 cycles – which is usually equivalent to 10 years of use.

Recharge time.

1 kWh lithium:

  • From 0-80% in about 60 mins from DC and mains

  • 2x faster recharging time with the supercharger – from 0-80% in half an hour (only from alternator)

  • 400W recharges from solar, from 0-80%, in 90 mins (which is why solar is often used to reduce fuel consumption and for off-grid)

  • You can use mains, supercharger and solar in combination to recharge even faster

LPS II 3000 - 2 kWh

230 V/50 Hz output

Peak: 5000 W

Power: 3000 W

12 V output

60 Seconds: 350 A

Continously: 180 A

Built-in Li-Ion Battery

Efficient energy: 2 kWh

Capacity: 2160 Wh (160 A)

Charging

Alternator: 500 W / SC: 1000 W

Solar panels: 400 W

Mains: 750 W



All in One built in 2 kWh Li-Ion battery, allowing you to charge quickly and efficiently from Alternator, Mains or Solar panels. With a built-in lithium battery the LPS is extremely compact and has a very long lifetime, but it is not possible to change the built-in lithium battery. There are currently more than 35,000 Clayton Power products in use across the UK and Europe.

The meaning of 2 kWh power.

The lithium battery capacity of 1 kWh means that you can run an application with a consumption of 1000 W in one hour, 500 W for two hours and 250 W for four hours. A 2 kWh battery has twice the capacity.
Example: Power tools 500 W x 1 hour + Light 150 W x 5 hours = 1,25 kWh

The number of cycles.

The battery can handle 2000 cycles – which is usually equivalent to 10 years of use.

Recharge time.

2 kWh lithium:

  • From 0-80% in about 120 mins from DC and mains

  • 2x faster recharging time with the supercharger – from 0-80% in one hour (only from alternator)

  • 400W recharges from solar, from 0-80%, in 240 mins (which is why solar is often used to reduce fuel consumption and for off-grid)

  • You can use mains, supercharger and solar in combination to recharge even faster
